VISION SERVICES

HEXAGON OPTIV ADVANTAGE

SPECIFICATIONS

  • 1500mm LENGTH
  • 600mm WIDTH
  • 300mm HEIGHT
  • 262x MAGNIFICATION
  • PC-DMIS Programmable

SUBMICRON REPEATABILITY

System accuracy is dependent upon measurement volume. Factory specification of entire system volume is 1.5+2L/1000 (μm).

main_img_1112

VISION SYSTEM CASE STUDIES

APPLICATIONS

CIRCUIT BOARDS

Coupling 262x magnification with small measurement volume accuracy allows us to measure high tolerance artifacts with a high density of features.

2D APPLICATIONS

Vision is the best method for measuring 2D applications such as locations tactile probes can’t touch, inscriptions, graphics, bar & QR codes, scratches, various labels, and more.
